SCROLL SAW BL.7TPI W/PINS 6/PACK (SSB41001)

Name: SCROLL SAW BL.7TPI W/PINS 6/PACK (SSB41001)
Brand: Ubuntu Sales Hardware | Midrand Randjespark Shopping Centre
SKU: SSB41001
Price: 189.69 ZAR
Availability: InStock

R189.69

SCROLL SAW BL.7TPI W/PINS 6/PACK

Product successfully added to the Quote List

SKU: SSB41001 Category: Cutting

Description

Brand:

TORK CRAFT

Product Code:

SSB41001

Barcode:

012373410010

Scroll saw blades pinned Pinned blades 127mm (5″) for a scroll saw. LENGTH: 127mm

Scroll saw blades pinned

Olsonblades Sm1

Pinned blades 127mm (5″) for a scroll saw.

LENGTH: 127mm (5″) between pins
TPI: 7
PINS: Yes

Application:

The blades are manufactured to be used with Olsonblades Sm2 scroll saws.

There are various blade types available in the range with different teeth styles for different uses.

A minimum pilot hole of 4.7mm is required for cut-outs. Take a look at the chart below to select the correct blade for the recommended material and thickness.

Scroll saw blade selection chart:

CODE	TPI	TOOTH	APPLICATION + MAX. MATERIAL THICKNESS
42401	18.5	Skip tooth	Very thin cuts in hard and soft woods. 19mm
40501	20	Regular	Thin cuts in hard and soft woods. 19mm
41001	7	Hook	Cut thick hard and soft woods. 51mm
41101	15	Regular	General purpose blade for woods & plastic. 19mm
41201	10	Regular	Fast cutting of hard and soft woods. 19mm
42003	9/5	Skip tooth	Fast cut blade with reversed teeth for woods. 19mm
42701	25	Regular	Fine cuts in aluminium, plastic, soft woods & veneer to 19mm

DEFINITION:
TPI – Teeth per inch. The amount of teeth measured between 25.4mm

Note:
Some blades have reversed teeth for fast paced cutting. Take care when using these blades as the blades can lift up your project from the scroll saw table when cutting.
